Application Field
-
Lithium Battery Industry
-
Textile Industry
-
Soft Packaging Industry
Product Characteristics
1 Built-in multiple protection mechanisms such as short circuit, overvoltage, and overcurrent protection. These mechanisms ensure that the device automatically cuts off the output in abnormal situations, preventing damage to the circuit and extending the service life of the device.
2 Users can flexibly adjust the output voltage to achieve precise control.
3 Compact size reduces the number of external components, enhances stability, and at the same time lowers energy consumption and noise.
4 The compact design facilitates easy installation and maintenance, making it suitable for various spatial layouts.
5 Supports remote control function.
Performance Parameter
- Model ParametersYP-HV50KV
- Input VoltageAC220V±10%/50Hz
- Output VoltageAdjustable from 0 to ±50KV
- Output Current≤1mA
- Ripple Voltage-
- Output Stability-
- Operating Temperature-10-50℃
- Storage Temperature-40-85℃
- Operating Humidity20-85%RH
- Temperature Coefficient≤0.1%/℃
- Time Drift≤100PPM/h (after 30 minutes of warm-up after power-on)
- Weight7500g
Product Size
